“Optical Sensors Embedded within AMLCD Panel: Design and Applications” by Abileah and Green
Conference:
- SIGGRAPH 2007
-
More from SIGGRAPH 2007:
Type(s):
Entry Number: 17
Title:
- Optical Sensors Embedded within AMLCD Panel: Design and Applications
Presenter(s):
Description:
A new approach to data input into AMLCD panels has been conceived and demonstrated. This integrates an array of TFT optical sensors into the a-Si backplane of the AMLCD. The concept, design considerations, and specific applications such as touch panel input, hand recognition, and image capture will be discussed.
Other Information:
References
[1] W. den Boer et al. “Active Matrix LCD with Integrated Optical Touch Screen”; SID’03 (Baltimore) pg.1494–1497.
[2] P.G.J. Barten, “Contrast Sensitivity of the Human Eye”, SPIE Press, 1999.
[3] A. Abileah et al. “Integrated optical Touch Panel in a 14.1” AMLCD”; SID’04 (Seattle) pg.1544-1547.
[4] A. Abileah et al. “Optical Sensors Embedded within AMLCD panel: Design and Applications”; ADEAC’06, SID (Atlanta) pg. 102-105
[5] S.J. Hong et al. “Smart LCD using a-Si photo sensor”; IMID’05 Digest pg. 280-283
[6] C. Brown et al, “A 2.6 inch VGA LCD with Optical Input Function using a 1-Transistor Active-Pixel Sensor”; ISSCC 2007 (&7.2) pg.132-133
[7] Booth demo of several Toshiba Matsushita image capture AMLCDs based on poly-silicon technology; SID 2004-2006 exhibitions. No papers presented.
[8] D.J. Tulbert, “Low Cost, Display-Based, Photonic Touch Interface with Advanced Functionality”; SID 05 Digest (Boston) pg. 1222-1225
Additional Images:
![©Adi Abileah and Patrick Green](https://history.siggraph.org/wp-content/uploads/2021/11/2007-ETech-Abileah-Optical-Sensors-Embedded-within-AMLCD-Panel-03.jpg)
![©Adi Abileah and Patrick Green](https://history.siggraph.org/wp-content/uploads/2021/11/2007-ETech-Abileah-Optical-Sensors-Embedded-within-AMLCD-Panel-06.jpg)
![©Adi Abileah and Patrick Green](https://history.siggraph.org/wp-content/uploads/2021/11/2007-ETech-Abileah-Optical-Sensors-Embedded-within-AMLCD-Panel-05.jpg)
![©Adi Abileah and Patrick Green](https://history.siggraph.org/wp-content/uploads/2021/11/2007-ETech-Abileah-Optical-Sensors-Embedded-within-AMLCD-Panel-04.jpg)
Acknowledgements:
The authors express their appreciation to the AU Optronics team for the design and manufacturing of the displays with sensor arrays.
