“A Full-Color Single-Chip-DLP Projector with an Embedded 2400-fps Homography Warping Engine” by Kagami and Hashimoto

  • ©Shingo Kagami and Koichi Hashimoto

  • ©Shingo Kagami and Koichi Hashimoto

Title:


    A Full-Color Single-Chip-DLP Projector with an Embedded 2400-fps Homography Warping Engine

Presenter(s):


Entry Number: 01


Description:


    We demonstrate a 24-bit full-color projector that achieves over 2400-fps motion adaptability to a fast moving planar surface using single-chip DLP technology, which will be useful for projection mapping applications in highly dynamic scenes. The projector can be interfaced with a host PC via standard HDMI and USB without need of high computational burden.

References:


    Oliver Bimber, Daisuke Iwai, Gordon Wetzstein, and Anselm Grundhöfer. 2007. The Visual Computing of Projector-Camera Systems. In State-of-The-Art Report, EUROGRAPHICS 2007.

    Donald B. Doherty, CarlW. Davis, Joseph G. Egan, and Robert Gove. 1999. Bit-Splitting for Pulse Width Modulated Spatial Light Modulator. US Patent 5,969,710. (1999).

    Shingo Kagami and Koichi Hashimoto. 2015. Sticky Projection Mapping: 450-fps Tracking Projection onto a Moving Planar Surface. In SIGGRAPH Asia 2015 Emerging Technologies. Article no.23.

    Peter Lincoln, Alex Blate, Montek Singh, Turner Whitted, Andrei State, Anselmo Lastra, and Henry Fuchs. 2016. From Motion to Photons in 80 Microseconds: Towards Minimal Latency for Virtual and Augmented Reality. IEEE TVCG 22, 4 (2016), 1367–1376.

    Albert Ng, Michelle Annett, Paul Dietz, Anoop Gupta, and Walter F. Bischof. 2014. In the Blink of an Eye: Investigating Latency Perception during Stylus Interaction. In CHI 2014.

    Y. Watanabe, G. Narita, S. Tatsuno, T. Yuasa, K. Sumino, and M. Ishikawa. 2015. High-Speed 8-bit Image Projector at 1,000 fps with 3 ms Delay. In Proc. 22nd International Display Workshop (IDW’15). PRJ2-4L.

    Feng Zheng, Turner Whitted, Anselmo Lastra, Peter Lincoln, Andrei State, Andrew Maimone, and Henry Fuchs. 2014. Minimizing Latency for Augmented Reality Displays: Frames Considered Harmful. In ISMAR 2014. 195–200.


Acknowledgements:


    This work is partially supported by JST ACCEL JPMJAC1601 and JSPS Grant-in-Aid 16H02853 and 16H06536.


Additional Images:

©Shingo Kagami and Koichi Hashimoto ©Shingo Kagami and Koichi Hashimoto ©Shingo Kagami and Koichi Hashimoto
