“Aerial 3D Display using a Symmetrical Mirror Structure” by Fujiwara and Hamamoto

  • ©

  • ©

  • ©

Conference:


Type(s):


Entry Number: 31

Title:

    Aerial 3D Display using a Symmetrical Mirror Structure

Presenter(s)/Author(s):



Abstract:


    In the present study, we propose a new wide-viewing-angle aerial imaging display that can display aerial three-dimensional images to the surroundings. Aerial imaging has a strong visual impact, and significant efforts have been made to realize aerial imaging. In recent years, attention has been drawn to optical elements that realize retroreflective transmission, which makes it possible to easily project such images into the air. However, the viewing angle of the aerial image is narrow, and it is difficult for multiple people to simultaneously observe aerial images or to observe aerial images from all angles. Therefore, in the present study, by symmetrically arranging the mirrors at the end of the retro reflective optical transfer system, the maximum viewing angle of the aerial image is enlarged and observation from the entire circumference becomes possible.

References:


    • Hajime Kajita, Naoya Koizumi, and Takeshi Naemura. 2016. SkyAnchor: Optical Design for Anchoring Mid-air Images onto Physical Objects. In Proceedings of the 29th Annual Symposium on User Interface Software and Technology (UIST ’16). 415–423.
    • Hiroki Yamamoto, Hajime Kajita, Naoya Koizumi, and Takeshi Naemura. 2015. EnchanTable: Displaying a Vertically Standing Mid-air Image on a Table Surface Using Reflection. In Proceedings of the 2015 International Conference on Interactive Tabletops & Surfaces (ITS ’15). 397–400.

Keyword(s):



Additional Images:

© ©

PDF:



ACM Digital Library Publication:



Overview Page:
