“Wired Muscle: Generating Faster Kinesthetic Reaction by Inter-personally Connecting Muscles” by Nishida, Kasahara and Suzuki
Conference:
- SIGGRAPH 2017
-
More from SIGGRAPH 2017:
Type(s):
Entry Number: 26
Title:
- Wired Muscle: Generating Faster Kinesthetic Reaction by Inter-personally Connecting Muscles
Presenter(s):
Description:
Instantaneously generating own body movements in response to the movement of others, such as establishing defensive posture in sports and learning kick-out timing from therapists in gait rehabilitation, is an essential aspect of interpersonal exercises and contact sports. However, ignition of movement based on a visual stimulus requires approximately 250 milliseconds (ms), which is too late for certain interpersonal physical interactions that require immediate reaction. Thus, we introduce “Wired Muscle,” a system that connects muscle activities between two persons using electromyogram (EMG) measurement and electrical muscle stimulation (EMS) to generate responsive movement that are faster than those generated by the visual information-based process. Our system detects the muscle activity of a person by the EMG and triggers the EMS to drive the muscle of the other person to induce corresponding counter movements. In a pilot study using our system, the reaction time to the motion of another person could be shortened to approximately 60 ms. In addition, some participants perceive that the kinesthetic reaction was performed by their own will even though the muscle movement was electrically driven by prior stimuli. We envision that our system will enable direct connection of kinesthetic experiences among multiple persons and will form the basis for a novel paradigm of motor learning.
References:
Shunichi Kasahara, Mitsuhito Ando, Kiyoshi Suganuma, and Jun Rekimoto. 2016. Parallel Eyes: Exploring Human Capability and Behaviors with Paralleled First Person View Sharing. In Proceedings of the 2016 CHI Conference on Human Factors in Computing Systems (CHI ’16). ACM, New York, NY, USA, 1561–1572. https://doi.org/10.1145/2858036.2858495
Pedro Lopes, Alexandra Ion, and Patrick Baudisch. 2015. Impacto: Simulating Physical Impact by Combining Tactile Stimulation with Electrical Muscle Stimulation. In Proceedings of the 28th Annual ACM Symposium on User Interface Software & Technology (UIST ’15). ACM, New York, NY, USA, 11–19. https://doi.org/10.1145/2807442.2807443
Jun Nishida and Kenji Suzuki. 2017. bioSync: A Paired Wearable Device for Blending Kinesthetic Experiences. In Proceedings of the 2017 CHI Conference on Human Factors in Computing Systems (CHI ’17). ACM, New York, NY, USA, 12. https://doi.org/10.1145/3025453.3025829
Emi Tamaki, Takashi Miyaki, and Jun Rekimoto. 2011. PossessedHand: Techniques for Controlling Human Hands Using Electrical Muscles Stimuli. In Proceedings of the SIGCHI Conference on Human Factors in Computing Systems (CHI ’11). ACM, New York, NY, USA, 543–552. https://doi.org/10.1145/1978942.1979018
Keyword(s):
- kinesthetic experience
- electrical muscle stimulation
- electromyogram
- interpersonal connection
Additional Images:
![©Jun Nishida, Shunichi Kasahara, and Kenji Suzuki](https://history.siggraph.org/wp-content/uploads/2022/04/2017-ETech-26-Nishida_Wired-Muscle-03.jpg)
![©Jun Nishida, Shunichi Kasahara, and Kenji Suzuki](https://history.siggraph.org/wp-content/uploads/2022/04/2017-ETech-26-Nishida_Wired-Muscle-04.jpg)
