“Primal-dual Non-smooth Friction for Rigid Body Animation”
Conference:
Type(s):
Title:
- Primal-dual Non-smooth Friction for Rigid Body Animation
Presenter(s)/Author(s):
Abstract:
Our novel contact solver, based on an primal-dual interior point algorithm, efficiently and robustly simulates the non-smooth transition between static and dynamic friction. Our algorithm is well suited for large systems of tightly packed objects with many contacts, which we demonstrate with complex granular flows and interlocking assemblies of rigid bodies.
